Hobbywing EZRun MAX6 V3 Sensorless Brushless ESC & Motor Combo w/5687SL (1100kV)
Original price was: $289.99.$65.00Current price is: $65.00.
- Effortless solutions, excellent customer care.
- Quick responses, top-notch service.
- Efficient and effective customer service, online.
- Green products, guaranteed.
The Hobbywing EZRun MAX6 V3 Sensorless Brushless ESC & Motor Combo includes the 5687SL 1/5 scale, 1150kV motor and is a great option for high-end, aggressively powered, large scale 8S builds.
Specifications:
- Motor:
- Model: 5687SL-1100KV
- Pole: 4
- KV (No-load): 1100KV
- Resistance: 0.0041 Ω
- Current (No-load): 4.1 A
- Max Output Power: 5800 W
- Current at the point of M.O.P: 200 A
- Motor Diameter: 56mm
- Motor Length: 87mm
- Shaft Diameter: 8.0mm
- Shaft Length: 31.0mm
- LiPo Cells: 3-8
- Weight: 916g (32.21oz)
- Applicable: 1/5th RC Vehicles Truck/Dragster
- ESC:
- Continuous Current: 160A
Peak Current: - Peak Current:
- Peak Current: 1,050A
- Motor Type: Sensorless Brushless Motor
- Applications: 1/6th Touring Car, Buggy, Truggy and Truck
- Motor Limit: With 6S LiPo/18S NiMH: KV ≤1500 (5892 size motor); With 8S LiPo/24S NiMH: KV ≤1200 (5892 size motor)
- LiPo/NiMH Cells: 9-24S NiMH, 3-8S LiPo
- BEC Output: 6V/7.2V Switchable, Continuous Current of 6A (Switch-mode BEC)
- Cooling Fan: Powered by the stable BEC voltage of 6V/7.2V
- Connectors: Input End: None, Output End: Female 6.5mm Gold Connectors (pre-soldered onto the PCB of the speed controller)
- Size (LxWxH): 70x56x46.5mm
- Weight: 240g
- Programming Port: FAN /PRG Port
This product was added to our catalog on April 25, 2019
